- Manufacturer
- Richmond Luxury Vinyl
- Application
- Residential and Commercial
- Castor Chair Test
- (ISO 4918) Pass
- Certification
- Greenguard Gold
- Chemical Resistance
- (ASTM F963) Meet Official Requirement
- Coefficient of Friction
- (ASTM C1028) > 0.3
- Collection Name
- Corestone Tile
- Color
- Gray
- Color Variation
- (V1) Low Variation
- Colourfastness
- (ASTM F1515) ΔE ≤8
- Commercial Warranty (years)
- 5
- Core Type Detail
- Waterproof SPC Core
- Coverage (sqft)
- 23.25
- Coverage (sqyd)
- 2.58
- Dimensional Stability
- (ASTM F2199) Pass
- Edge Type
- 4-Sided Color Matched Bevel
- Fire Resistance
- (EN 13501) Bf1-S1
- FloorScore Certified
- No
- Format (in.)
- 12" x 24"
- Gloss Level (%)
- 5-8%
- Grade Level
- On, above or below grade
- IIC Delta Rating
- 28
- IIC Rating
- 60
- Indoor Usage
- Yes
- Installation Method
- Click Lock
- Installation Method Precision
- Click Floating - Angle/tap
- Length (cm)
- 60
- Length (ft)
- 2
- Length (in.)
- 24
- Length (inches in fraction)
- 24
- Length (m)
- 6
- Length (mm)
- 600
- Locking Mechanism
- Click Floating - Angle/tap
- Look
- Stone
- Maintenance
- One of the easiest floors to maintain. Vacuum, mop and spot clean.
- Manufacturer Color Name
- Chase
- Material
- Luxury Vinyl
- Maximum Exposure Temperature
- 40°C (100°F)
- Maximum Installation Temperature
- 25°C (80˚F)
- Maximum Length without Transition Molding
- 4000 sqft
- Minimum Exposure Temperature
- 10°C (50°F)
- Minimum Installation Temperature
- 20°C (60˚F)
- Moisture Resistant
- Yes
- Origin Country
- China
- Pattern Repeat Frequency
- At Every 6 Planks
- Peel Resistance
- (EN 431) ≥ 60 N/50 mm
- Radiant Heat Compatible
- Yes
- Radiant Heat Type
- Hydronic Heat Only, Must not exceed 30°C (85°F)
- Recycled Content
- 0 %
- Residential Warranty (years)
- 25
- STC Rating
- 51
- Shade Level
- Medium Shade
- Slip Resistant
- Yes
- Squareness and Straightness Standard
- (ASTM F2055:ISO 24342) ≤ 0.25 mm
- Stain Resistance
- (EN 423) No more than slight change
- Static Load Limit ASTM F 970
- (ASTM F970) ≤ 0.13 mm
- Subfloor Type
- Wood and Concrete
- Surface Texture
- Embossed
- Surface Treatment
- High Quality Urethane
- TVOC Emission
- ≤220 µg
- Temperature Range
- Indoor temperature range recommendation is -30°C to 60°C. Make sure that the temperature in the room is at least 15°C (60°F) during installation
- Thickness (cm)
- 0.53
- Thickness (in.)
- 0.21
- Thickness (inches in fraction)
- 3/16
- Thickness (mm)
- 5.3
- Traffic Classification
- Residential: Class 21 - Domestic moderate / Class 22 - Domestic general / Class 23 - Domestic Heavy | Light Commercial: Class 31 - Commercial moderate / Class 32 - Commercial general | Commercial: Class 33 - Commercial heavy
- Underpad Attached
- Yes
- Underpad Thickness (mm)
- 1
- Underpad Type
- IXPE Pad
- Use On
- Floors
- Use With
- Spacers, rubber mallet, ruler, pencil, tape measure, utility knifeé. Use Expansion moldings if floor surfaces exceed 6400 sqft and/or exceed 80 linear feet
- Warranty
- 25-Year Residential | 5-Year Light Commercial
- Water Resistant
- Yes
- Waterproof
- Yes
- Wear Layer Finish
- UV
- Wear Layer Thickness (mil)
- 12
- Wear Layer Thickness (mm)
- 0.3
- Wear Resistance
- (EN 13329) ≥ 4000R
- Weight (kg)
- 19.72
- Weight (lb)
- 43.47
- Width (cm)
- 30
- Width (in.)
- 12
- Width (inches in fraction)
- 12
- Width (mm)
- 300
